3.5 Ton 14.5 SEER2 Goodman AC Split System GSXN404210+AMST42CU1400 (Not a Heat Pump)
3.5 Ton 14.5 SEER2 Goodman AC Split System GSXN404210+AMST42CU1400
Standard Features
• Energy-Efficient Compressor
• Copper tube/ enhanced aluminum fin coil-5mm diameter on 1.5-4.0T
• Factory-installed filter drier
• Fully charged for 15’ of tubing length
• Service valves with sweat connections and easy-to-access gauge ports
• Contactor with lug connection
• Ground lug connection
• AHRI Certified
• ETL Listed
Cabinet Features
• Removable grille-style top design compliant with UL 60335-2-40
• Heavy-gauge galvanized-steel cabinet
• Attractive Architectural Gray powder-paint finish with 500-hour salt-spray approval
• Steel louver coil guard
• Single-panel access to controls with space provided for field-installed accessories
• When properly anchored, meets the 2020 Florida Building Code unit integrity requirements for hurricane-type winds (Anchor bracket kits available.)
GSXN404210
| GSXN404210 | |
| Capacities | |
| Nominal Cooling (BTU/h) | 42,000 |
| Decibels (dBA) | 71 |
| Compressor | |
| RLA | 17.7 |
| LRA | 110.2 |
| Stage | Single |
| Type | Scroll |
| Condenser Fan Motor | |
| Motor Type | PSC |
| Horsepower | 1/6 |
| FLA | 0.97 |
| Refrigeration System | |
| Refrigerant Line Size | |
| Liquid Line Size (“O.D.) | ⅜" |
| Suction Line Size (“O.D.) | ⅞" |
| Refrigerant Connection Size | |
| Liquid Valve Size (“O.D.) | ⅜" |
| Suction Valve Size | ⅞" |
| Valve Type | Sweat |
| Refrigerant Charge | 107 |
| Electrical Data | |
| Voltage-Phase (60 Hz) | 208/230-1 |
| Minimum Circuit Ampacity | 23.1 |
| Max. Overcurrent Protection | 40 |
| Min / Max Volts | 197/253 |
| Electrical Conduit Size | ½" or ¾" |
| Equipment Weight (lbs) | 226 |
| Ship Weight (lbs) | 248 |
Product Features
• Internal factory-installed thermal expansion valves for cooling and heat pump applications
• Direct drive, multi-speed ECM blower motor
• All-aluminum evaporator coil
• Coil mounting track for quick repositioning
• Optimized for use with R-410A refrigerant
• Cabinet air leakage less than 2.0% at 1.0 inch H₂O when tested in accordance with ASHRAE standard193
• Cabinet air leakage less than 1.4% at 0.5 inch H₂O when tested in accordance with ASHRAE standard193
• AHRI certified; ETL listed
• Rigid SmartFrame™ cabinet
• Horizontal or vertical configuration capabilities
• 21” depth for easier attic access
• DecaBDE-free thermoplastic drain pan with secondary drain connections
• Screw-less sides and back helps to reduce con- densation when installed in humid locations
• Foil-faced insulation covers the internal casing to reduce cabinet condensation
• Galvanized, leather grain-embossed finish
• Glue-less cabinet insulation retention
• Tool-less filter access
• Field Installed 3 kW – 25 kW electric heater kits available
AMST42CU1400
| AMST42CU1400 | |
| Nominal Ratings | |
| Cooling (Btu/h) | 42,000 |
| Blower | |
| Diameter | 10" |
| Width | 8" |
| Coil Connections | |
| Liquid | 3/8" |
| Suction | 3/4” |
| Coil Drain Connect (FPT) | 3/4” |
| Electrical Data | |
| Voltage | 208/230 |
| Minimum Circuit Ampacity | 5.9/5.9 |
| Max. Overcurrent Device (Amps) | 15/15 |
| Minimum VAC | 197 |
| Maximum VAC | 253 |
| Blower Motor | |
| Full Load Amps (FLA) | 4.7 |
| Horsepower (HP) | ¾ |
| Ship Weight (Lbs.) | 153 |
AMST42CU1400 Heat Kit Specs
| Heater Kit Model | Circuit 1 | Circuit 2 | Single-Point Kit | |||||
| Heater Amps | Mininum Circuit Ampacity 208/230 | Max Over Current Protection 208/230 | Heater Amps | Mininum Circuit Ampacity 208/230 | Max Over Current Protection 208/230 | Mininum Circuit Ampacity 208/230 | Max Over Current Protection 208/230 | |
| AMST42CU1400 | 0/0 | 5.9/5.9 | 15/15 | |||||
| 3 KW | 10.8/12.5 | 19/21.5 | 20/25 | |||||
| 5 KW | 17.3/20 | 28/30.9 | 30/35 | |||||
| 6 KW | 21.7/25 | 33/37.1 | 35/40 | |||||
| 8 KW | 28.9/33.3 | 42/47.5 | 45/50 | |||||
| 10 KW | 34.7/40 | 49/55.9 | 50/60 | |||||
| 15 KW | 40 | 55.9 | 60 | 20 | 25 | 25 | 80.9 | 90 |
