Description
Features
- Self Priming
- Pump installs remotely above ceiling or inside lineset cover
- Pan mount and inline style reservoir included
- Modular terminals for fast connection
- Gravity Inlet
- Fully potted electronics*
- 3A NC dry contacts rated @ 5A inductive at 230V AC
Specifications:
Power Supply: 100-250 VAC
Power Consumption: .15-18A 21W
Duty Cycle:
- Mini – non-continuous
- Maxi – 50% 5 mins on / 5 mins off
Capacity:
Mini – Up to 54,600 BTU/hr.
3.2 GPH @ zero head,
1.6 GPH @ 33ft head
Maxi – Up to 157,000 BTU/hr.
8.9 GPH @ zero head,
1.5 GPH @ 50ft head
Maximum head:
Mini – 33ft Maxi – 49ft
Suction lift: 5ft
Sound level:
Mini – 21dB(A)-35dB(A)
Silent Plus – 19dB(A)
Pump Dimensions:
Mini: L-41/4” x W-11/2” x H-2”
Maxi: L-47/8” x W-13/4” x H-25/8”
